超声波发生器

超声波发生器：

1、超声波发生器，又称超声波驱动电源、超声波电箱，是大功率超声系统的重要组成部分

2、超声波发生器作用是把市电转换成与超声波换能器相匹配的高频交流电信号，驱动超声波换能器工作

3、大功率超声波电源从转换效率方面考虑一般采用开关电源的电路形式。

4、超声波电源分为自激式和它激式电源，自激式电源称为超声波模拟电源，它激式电源称为超声波发生器。

超声波发生器产品特点

Ultrasonic Generators Product Characteristics

单片机控制，IGBT工作模式，超声波输出功率较旧式电路增加15%以上，且连续无级可调，液晶显示。

超声波发生器装置工作电压220 V Ac±10％，超声波发生器具有过压，过流，输出短路等保护措施。

超声波发生器具有功率无级调节的功能，输出功率可实现10～100%的连续调整，以适应各种清洗对象的要求。

超声波发生器配备有数字式超声波工作时间0～999min 设定，精确到秒，实现无人自动值守。

Singlechip-control, IGBT operating mode, the ultrasonic output power is greater than that of the old style circuit by over 15%, and it works in a continuous way without adjustable steps, liquid-crystal display

The ultrasonic generator operating voltage 220 V AC±10％，and ultrasonic generator has various protective measures against the potential dangers of overvoltage, overcurrent and output short-circuit.

The ultrasonic generator has the function of stepless adjustment for its power, and its output power can realize 10～100% continuous adjustment, in order to better suit various objects to be cleaned.

The ultrasonic generator is equipped with digital display of ultrasonic work time 0～999min settings, correct to seconds, and it can control and regulate automatically , needless for care by people.
